Muck-Truck® Specifications, Wheelbarrow Specs

Gasoline Powered

H-Max™ - 8cu ft. skip/bucket

The H-Max has the same drive system, engine and carry capacity as the other machines, but adds hydraulic tipping for easier, more precise emptying of a part load. Perfect for working on pathways.
- Model:
  H-Max™
- Engine:
  Honda GXV 160 Commercial 5.5hp
- Transmission:
  3 forward / 1 reverse
- Speed:
  0-3.5mph
- Fuel:
  Unleaded Petrol
- Capacity:
  8cu/ft - 800lbs/365kg carrying capacity
- Noise Rating:
  Up to 98db
- Parking Brake:
  Disc
- Wheels:
  4 x 400x10, 4 ply tractive
- Dimensions:
  (L) 72” x (W) 29” x (H) 42”
  (L) 1830mm x (W) 735mm x (H) 1070mm
- Weight:
  Unladen weight - 410lbs/185kgs
- Traction:
  4 Wheel drive
Find out more
Max-Truck™ - 8cu ft. skip/bucket

The MAX Truck™ can carry 365kgs/800lbs/8cu ft and will climb a 30º slope fully loaded. The machine is fitted with the Honda GXV Commercial grade 5.5hp engine.
- Model:
  Max-Truck®
- Engine:
  Honda GXV 160 Commercial 5.5hp
- Transmission:
  3 forward / 1 reverse
- Speed:
  0-3.5mph
- Fuel:
  Unleaded Petrol
- Capacity:
  8 cu/ft - 800lbs/365kgs carrying capacity
- Noise Rating:
  Up to 98db
- Parking Brake:
  Disc
- Wheels:
  4 x 400x10, 4 ply tractive
- Dimensions:
  (L) 63" x (W) 28“ x (H) 36"
  (L) 1600 x (W) 710mm x (H) 915mm
- Weight:
  Unladen - 345lbs/155kgs
- Traction:
  4 Wheel drive
Find out more
Muck-Truck® - 6cu ft. skip/bucket

The Muck-Truck® original mini-dumper carries 250kgs/550lbs/6cubic feet and climbs 30° slopes fully loaded. In production for 30+ years, it’s a true workhorse, trusted & recognised across the world.
- Model:
  Muck-Truck®
- Engine:
  Honda GXV 160 Commercial 5.5hp
- Transmission:
  3 forward / 1 reverse
- Speed:
  0-3.5mph
- Fuel:
  Unleaded Petrol
- Capacity:
  6 cu/ft - 550lbs/250kgs carrying capacity
- Noise Rating:
  Up to 98db
- Parking brake:
  Disc
- Wheels:
  Front 400x10, 4 ply tractive. Rear 400x8, 4 ply tractive
- Dimensions:
  (L) 61” x (W) 28“ x (H) 34”
  (L) 1550mm x (W) 710mm x (H) 865mm
- Weight:
  Unladen - 295lbs/135kg
- Traction:
  4 Wheel Drive
Find out more

Electric Powered

Ladybug 2WD

The Ladybug 2WD is the latest model in our range, designed with meticulous attention to detail and an unwavering commitment to quality. Our decision to have developed this model stems from customer demands who requested a machine speciﬁcally to manage their own gardens, small holdings, and equestrian properties.
- Model:
  Ladybug 2WD
- Speed:
  0-3.5 mph/5.6kph FWD 0-1.75 mph/2.8kph REV
- Steering/Movement:
  Rear Caster / Swivel Wheel
- Skip/bucket Size:
  6cu ./170 liters
- Carrying Capacity:
  250kg / 550lbs.
- Machine Dimensions:
  L68 x W30 x H36 inches L170 x W76 x H91 cm
- Wheels:
  Front: 2 x 16 x 6.50-8 (Cleated) Rear: 1 x 11 x 4.00-5 (Treaded)
- Weight Unladen:
  175kg / 385lbs
- Noise Rating:
  Up to 5db
- Running Time:
  4 hrs. continuously
- Charging Time:
  80% (4 hrs.), 100% (6 hrs.)
- Max Slope:
  20 degrees
- Turning Radius:
  31 inches
- Battery Charger:
  Flexel High Powered 12Amp Smart Charger
- Power (W):
  950 Watts
Find out more
EGO Max

Combining the power of electric with the trusted Muck-Truck design, the EGO Max is the durable, easy to use machine every construction or landscaper needs – increasing productivity and reducing strain.
- Model::
  EGO Max
- Power:
  56V
- Transmission::
  Peerless Tecumseh
- Speed::
  0-3.5 mph/5.6 kph FWD
  0-1.75 mph/2.8 kph REV
  ECO and Turbo Mode
- Capacity::
  804.68lbs / 365kg
- Noise Rating::
  75 Dbs
- Parking Brake::
  N/A
- Wheels::
  Front: 2 x 16 x 6.50-8
  Rear: 2 x 16 x 6.50-8
- Dimensions:
  (L) 75" x (W) 30" x (H) 42"
  (L) 1900mm x (W) 760mm x (H) 1070mm
- Weight:
  307.87lbs / 139.65kg
- Traction:
  4-Wheel Drive
- Charging Time:
  1 hr. (100%) x 1 battery
- Continuous Run Time:
  1.30 hrs. continuously
  (Turbo Mode, 2 x 12Ah Batteries)
- Working Hours:
  3.5 hrs per charge
Find out more
Power Barrow 4WD II - 8cu ft. skip/bucket

The Power Barrow 4WD II by Muck Truck is electric (battery) powered, features a four wheel drive that makes it easy to manoeuvre, and is equipped with electronic tipping by just a touch of a button.
- Model:
  Power Barrow 4WD
- Power:
  2 x 12 Volts Battery/1800 Watts
- Transmission:
  Electric Transmission
- Speed:
  0 – 4.00 mph variable speed
- Capacity:
  8 cu/ft - 800lbs/365kg carrying capacity
- Noise rating:
  5 dB
- Parking Brake:
  Electromagnetic release
- Wheels:
  Front 16x6.50-8, Rear 16x6.50-8 (4 ply tractive)
- Dimensions:
  L71.5 x W30.5 x H39.5 inches
- Weight:
  265kg
- Traction:
  4 Wheel Drive
- Charging time:
  80% (4 hrs.), 100% (6 hrs.)
- Continuously Run Time:
  3.5 Hrs
- Working Hours:
  8 Hrs
Find out more
